9FEN | pdb_00009fen

LSSmOrange (P1) - Directionality of Optical Properties of Fluorescent Proteins

PDB DOI: https://doi.org/10.2210/pdb9FEN/pdb

Classification: FLUORESCENT PROTEIN
Organism(s): Aequorea victoria
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2024-05-21 Released: 2025-06-04
Deposition Author(s): Myskova, J., Brynda, J., Lazar, J.
Funding Organization(s): Ministry of Education, Youth and Sports of the Czech Republic, Czech Science Foundation

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.60 Å
R-Value Free:
0.199 (Depositor), 0.206 (DCC)
R-Value Work:
0.170 (Depositor), 0.176 (DCC)
R-Value Observed:
0.171 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Directionality of Optical Properties of Fluorescent Proteins

Myskova, J., Brynda, J., Khoroshyy, P., Lazar, J.

To be published.

Macromolecule Content

Total Structure Weight: 27.88 kDa
Atom Count: 2,107
Modeled Residue Count: 229
Deposited Residue Count: 246
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
nowGFP crystallized in Space Group C2	A	246	Aequorea victoria	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Small Molecules

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
CRF Query on CRF	A	L-PEPTIDE LINKING	C₁₇ H₁₈ N₄ O₄		THR, TRP, GLY

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.60 Å
R-Value Free: 0.199 (Depositor), 0.206 (DCC)
R-Value Work: 0.170 (Depositor), 0.176 (DCC)
R-Value Observed: 0.171 (Depositor)

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 111.9	α = 90
b = 51.48	β = 100.5
c = 55.63	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data scaling
XDS	data reduction
MOLREP	phasing

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2025-06-04

Deposition Author(s):

Funding Organization	Location	Grant Number
Ministry of Education, Youth and Sports of the Czech Republic	Czech Republic	CZ.02.1.01/0.0/0.0/16_019/0000729
Czech Science Foundation	Czech Republic	23-05983S

Revision History (Full details and data files)

Version 1.0: 2025-06-04
Type: Initial release
