6QPU

Crystal structure of as isolated synthetic core domain of nitrite reductase from Ralstonia pickettii (residues 1-331)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.25 Å
  • R-Value Free: 0.237
  • R-Value Work: 0.179

wwPDB Validation 3D Report Full Report


This is version 1.0 of the entry. See complete history

Literature

Unexpected Roles of a Tether Harboring a Tyrosine Gatekeeper Residue in Modular Nitrite Reductase Catalysis

Hedison, T.M.Shenoy, R.T.Iorgu, A.I.Heyes, D.J.Fisher, K.Wright, G.Hay, S.Eady, R.R.Hasnain, S.S.Scrutton, N.S.

(2019) Acs Catalysis --: --


Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Copper-containing nitrite reductase
A, B, C, D, E, F
331Ralstonia sp. 5_2_56FAAMutation(s): 0
EC: 1.7.2.1
Find proteins for U3G913 (Ralstonia sp. 5_2_56FAA)
Go to UniProtKB:  U3G913
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
CL
Query on CL

Download SDF File
Download CCD File
A, B, D, E
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
 Ligand Interaction
PG4
Query on PG4

Download SDF File
Download CCD File
A, E
TETRAETHYLENE GLYCOL
C8 H18 O5
UWHCKJMYHZGTIT-UHFFFAOYSA-N
 Ligand Interaction
CU
Query on CU

Download SDF File
Download CCD File
A, B, C, D, E, F
COPPER (II) ION
Cu
JPVYNHNXODAKFH-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.25 Å
  • R-Value Free: 0.237
  • R-Value Work: 0.179
  • Space Group: C 2 2 21
Unit Cell:
Length (Å)Angle (°)
a = 165.884α = 90.00
b = 167.520β = 90.00
c = 143.982γ = 90.00
Software Package:
Software NamePurpose
Aimlessdata scaling
MOLREPphasing
REFMACrefinement
XDSdata reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Biotechnology and Biological Sciences Research CouncilUnited KingdomBB/N019380/1
Biotechnology and Biological Sciences Research CouncilUnited KingdomBB/N013972/1

Revision History

  • Version 1.0: 2019-11-06
    Type: Initial release
