1KL7

Crystal Structure of Threonine Synthase from Yeast


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free: 0.253
  • R-Value Work: 0.201

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history


Literature

Structure and function of threonine synthase from yeast.

Garrido-Franco, M.Ehlert, S.Messerschmidt, A.Marinkovic, S.Huber, R.Laber, B.Bourenkov, G.P.Clausen, T.

(2002) J Biol Chem 277: 12396-12405

  • DOI: https://doi.org/10.1074/jbc.M108734200
  • Primary Citation of Related Structures:
    1KL7

  • PubMed Abstract:

    Threonine synthase catalyzes the final step of threonine biosynthesis, the pyridoxal 5'-phosphate (PLP)-dependent conversion of O-phosphohomoserine into threonine and inorganic phosphate. Threonine is an essential nutrient for mammals, and its biosynthetic machinery is restricted to bacteria, plants, and fungi; therefore, threonine synthase represents an interesting pharmaceutical target. The crystal structure of threonine synthase from Saccharomyces cerevisiae has been solved at 2.7 A resolution using multiwavelength anomalous diffraction. The structure reveals a monomer as active unit, which is subdivided into three distinct domains: a small N-terminal domain, a PLP-binding domain that covalently anchors the cofactor and a so-called large domain, which contains the main of the protein body. All three domains show the typical open alpha/beta architecture. The cofactor is bound at the interface of all three domains, buried deeply within a wide canyon that penetrates the whole molecule. Based on structural alignments with related enzymes, an enzyme-substrate complex was modeled into the active site of yeast threonine synthase, which revealed essentials for substrate binding and catalysis. Furthermore, the comparison with related enzymes of the beta-family of PLP-dependent enzymes indicated structural determinants of the oligomeric state and thus rationalized for the first time how a PLP enzyme acts in monomeric form.


  • Organizational Affiliation

    Max-Planck-Institut für Biochemie, Abteilung Strukturforschung, am Klopferspitz 18A, Martinsried 82152, Germany.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Threonine Synthase
A, B
514Saccharomyces cerevisiaeMutation(s): 7
EC: 4.2.99.2 (PDB Primary Data), 4.2.3.1 (UniProt)
UniProt
Find proteins for P16120 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P16120
Go to UniProtKB:  P16120
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP16120
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A, B
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free: 0.253
  • R-Value Work: 0.201
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 95.3α = 90
b = 51.6β = 99.6
c = 106.9γ = 90
Software Package:
Software NamePurpose
SHARPphasing
CNSrefinement
DENZOdata reduction
CCP4data scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2002-04-24
    Type: Initial release
  • Version 1.1: 2008-04-27
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Non-polymer description, Version format compliance
  • Version 1.3: 2018-01-31
    Changes: Database references
