5RUF

PanDDA analysis group deposition -- Crystal structure of SARS-CoV-2 NSP3 macrodomain in complex with ZINC000016989831


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.00 Å
  • R-Value Free: 0.167
  • R-Value Work: 0.151
  • R-Value Observed: 0.152

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.5 of the entry. See complete history


Literature

Fragment binding to the Nsp3 macrodomain of SARS-CoV-2 identified through crystallographic screening and computational docking.

Schuller, M.Correy, G.J.Gahbauer, S.Fearon, D.Wu, T.Diaz, R.E.Young, I.D.Carvalho Martins, L.Smith, D.H.Schulze-Gahmen, U.Owens, T.W.Deshpande, I.Merz, G.E.Thwin, A.C.Biel, J.T.Peters, J.K.Moritz, M.Herrera, N.Kratochvil, H.T.Aimon, A.Bennett, J.M.Brandao Neto, J.Cohen, A.E.Dias, A.Douangamath, A.Dunnett, L.Fedorov, O.Ferla, M.P.Fuchs, M.R.Gorrie-Stone, T.J.Holton, J.M.Johnson, M.G.Krojer, T.Meigs, G.Powell, A.J.Rack, J.G.M.Rangel, V.L.Russi, S.Skyner, R.E.Smith, C.A.Soares, A.S.Wierman, J.L.Zhu, K.O'Brien, P.Jura, N.Ashworth, A.Irwin, J.J.Thompson, M.C.Gestwicki, J.E.von Delft, F.Shoichet, B.K.Fraser, J.S.Ahel, I.

(2021) Sci Adv 7

  • DOI: https://doi.org/10.1126/sciadv.abf8711
  • Primary Citation of Related Structures:
    5RS7, 5RS8, 5RS9, 5RSB, 5RSC, 5RSD, 5RSE, 5RSF, 5RSG, 5RSH, 5RSI, 5RSJ, 5RSK, 5RSL, 5RSM, 5RSN, 5RSO, 5RSP, 5RSQ, 5RSR, 5RSS, 5RST, 5RSU, 5RSV, 5RSW, 5RSX, 5RSY, 5RSZ, 5RT0, 5RT1, 5RT2, 5RT3, 5RT4, 5RT5, 5RT6, 5RT7, 5RT8, 5RT9, 5RTA, 5RTB, 5RTC, 5RTD, 5RTE, 5RTF, 5RTG, 5RTH, 5RTI, 5RTJ, 5RTK, 5RTL

  • PubMed Abstract:

    The severe acute respiratory syndrome coronavirus 2 (SARS-CoV-2) macrodomain within the nonstructural protein 3 counteracts host-mediated antiviral adenosine diphosphate-ribosylation signaling. This enzyme is a promising antiviral target because catalytic mutations render viruses nonpathogenic. Here, we report a massive crystallographic screening and computational docking effort, identifying new chemical matter primarily targeting the active site of the macrodomain. Crystallographic screening of 2533 diverse fragments resulted in 214 unique macrodomain-binders. An additional 60 molecules were selected from docking more than 20 million fragments, of which 20 were crystallographically confirmed. X-ray data collection to ultra-high resolution and at physiological temperature enabled assessment of the conformational heterogeneity around the active site. Several fragment hits were confirmed by solution binding using three biophysical techniques (differential scanning fluorimetry, homogeneous time-resolved fluorescence, and isothermal titration calorimetry). The 234 fragment structures explore a wide range of chemotypes and provide starting points for development of potent SARS-CoV-2 macrodomain inhibitors.


  • Organizational Affiliation

    Sir William Dunn School of Pathology, University of Oxford, South Parks Road, Oxford OX1 3RE, UK.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Non-structural protein 3
A, B
169Severe acute respiratory syndrome coronavirus 2Mutation(s): 0
Gene Names: rep1a-1b
EC: 3.4.22
UniProt
Find proteins for P0DTD1 (Severe acute respiratory syndrome coronavirus 2)
Explore P0DTD1
Go to UniProtKB:  P0DTD1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0DTD1
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
54T (Subject of Investigation/LOI)
Query on 54T

Download Ideal Coordinates CCD File
C [auth A]6-chloro-1,3-benzothiazol-2-amine
C7 H5 Cl N2 S
VMNXKIDUTPOHPO-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.00 Å
  • R-Value Free: 0.167
  • R-Value Work: 0.151
  • R-Value Observed: 0.152
  • Space Group: P 43
  • Diffraction Data: https://doi.org/10.18430/m35ruf
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 88.709α = 90
b = 88.709β = 90
c = 39.416γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XSCALEdata scaling
PDB_EXTRACTdata extraction
XDSdata reduction
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Science FoundationUnited States2031205

Revision History  (Full details and data files)

  • Version 1.0: 2020-12-16
    Type: Initial release
  • Version 1.1: 2021-01-27
    Changes: Structure summary
  • Version 1.2: 2021-05-12
    Changes: Structure summary
  • Version 1.3: 2021-06-09
    Changes: Structure summary
  • Version 1.4: 2022-05-25
    Changes: Database references
  • Version 1.5: 2024-05-22
    Changes: Data collection
