1E8D

MECHANISTIC ASPECTS OF CYANOGENESIS FROM ACTIVE SITE MUTANT SER80ALA OF HYDROXYNITRILE LYASE FROM MANIHOT ESCULENTA IN COMPLEX WITH ACETONE CYANOHYDRIN


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.238
  • R-Value Work: 0.186
  • R-Value Observed: 0.186

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Mechanistic Aspects of Cyanogenesis from Active-Site Mutant Ser80Ala of Hydroxynitrile Lyase from Manihot Esculenta in Complex with Acetone Cyanohydrin.

Lauble, H.Miehlich, B.Forster, S.Wajant, H.Effenberger, F.

(2001) Protein Sci 10: 1015

  • DOI: https://doi.org/10.1110/ps.01301
  • Primary Citation of Related Structures:
    1E89, 1E8D

  • PubMed Abstract:

    The structure and function of hydroxynitrile lyase from Manihot esculenta (MeHNL) have been analyzed by X-ray crystallography and site-directed mutagenesis. The crystal structure of the MeHNL-S80A mutant enzyme has been refined to an R-factor of 18.0% against diffraction data to 2.1-A resolution. The three-dimensional structure of the MeHNL-S80A-acetone cyanohydrin complex was determined at 2.2-A resolution and refined to an R-factor of 18.7%. Thr11 and Cys81 involved in substrate binding have been substituted by Ala in site-directed mutagenesis. The kinetic measurements of these mutant enzymes are presented. Combined with structural data, the results support a mechanism for cyanogenesis in which His236 as a general base abstracts a proton from Ser80, thereby allowing proton transfer from the hydroxyl group of acetone cyanohydrin to Ser80. The His236 imidazolium cation then facilitates the leaving of the nitrile group by proton donating.


  • Organizational Affiliation

    Institut für Organische Chemie der Universität Stuttgart, D-70569 Stuttgart, Germany. PeterLauble@t-online.de


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
HYDROXYNITRILE LYASE
A, B
262Manihot esculentaMutation(s): 1
EC: 4.2.1.37 (PDB Primary Data), 4.1.2.47 (UniProt)
UniProt
Find proteins for P52705 (Manihot esculenta)
Explore P52705
Go to UniProtKB:  P52705
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP52705
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.238
  • R-Value Work: 0.186
  • R-Value Observed: 0.186
  • Space Group: P 41 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 105.9α = 90
b = 105.9β = 90
c = 187.8γ = 90
Software Package:
Software NamePurpose
X-PLORrefinement
DENZOdata reduction
SCALEPACKdata scaling
X-PLORphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2001-08-17
    Type: Initial release
  • Version 1.1: 2013-01-30
    Changes: Database references, Derived calculations, Non-polymer description, Other, Version format compliance
  • Version 1.2: 2019-07-24
    Changes: Data collection
  • Version 1.3: 2023-12-13
    Changes: Data collection, Database references, Derived calculations, Other, Refinement description
