2YYN

Crystal structure of human bromodomain protein

• PDB DOI: https://doi.org/10.2210/pdb2YYN/pdb

• Classification: TRANSCRIPTION
• Organism(s): Homo sapiens
• Mutation(s): No


• Deposited: 2007-04-30 Released: 2008-05-06
• Deposition Author(s): Kishishita, S., Uchikubo-Kamo, T., Murayama, K., Terada, T., Shirouzu, M., Yokoyama, S., RIKEN Structural Genomics/Proteomics Initiative (RSGI)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.50 Å
• R-Value Free: 0.285
• R-Value Work: 0.239
• R-Value Observed: 0.239

Literature

Crystal structure of human bromodomain protein

Kishishita, S., Uchikubo-Kamo, T., Murayama, K., Terada, T., Shirouzu, M., Yokoyama, S.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors.

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 2 assigned by authors.

Biological Assembly 3

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 3 generated by PISA (software)

Biological Assembly 4

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 4 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 61.95 kDa
• Atom Count: 3,896
• Modelled Residue Count: 453
• Deposited Residue Count: 540
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Transcription intermediary factor 1-alpha	A, B, C, D	135	Homo sapiens	Mutation(s): 0  Gene Names: TRIM24, RNF82, TIF1, TIF1A EC: 2.3.2.27
UniProt & NIH Common Fund Data Resources
Find proteins for O15164 (Homo sapiens) Explore O15164  Go to UniProtKB:  O15164
PHAROS:  O15164 GTEx:  ENSG00000122779

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.50 Å
• R-Value Free: 0.285
• R-Value Work: 0.239
• R-Value Observed: 0.239
• Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 75.855	α = 90
b = 76.16	β = 90
c = 107.599	γ = 90

Software Package:

Software Name	Purpose
CNS	refinement
HKL-2000	data reduction
HKL-2000	data scaling
SOLVE	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2008-05-06
Deposition Author(s): Kishishita, S., Uchikubo-Kamo, T., Murayama, K., Terada, T., Shirouzu, M., Yokoyama, S., RIKEN Structural Genomics/Proteomics Initiative (RSGI)

Revision History

• Version 1.0: 2008-05-06
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Version format compliance
• Version 1.2: 2020-09-09
  Changes: Database references, Structure summary
• Version 1.3: 2022-12-21
  Changes: Database references
• Version 1.4: 2024-11-13
  Changes: Data collection, Structure summary
