2ISV

Structure of Giardia fructose-1,6-biphosphate aldolase in complex with phosphoglycolohydroxamate


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.261
  • R-Value Work: 0.199

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history


Literature

Characterization, kinetics, and crystal structures of fructose-1,6-bisphosphate aldolase from the human parasite, Giardia lamblia.

Galkin, A.Kulakova, L.Melamud, E.Li, L.Wu, C.Mariano, P.Dunaway-Mariano, D.Nash, T.E.Herzberg, O.

(2007) J Biol Chem 282: 4859-4867

  • DOI: https://doi.org/10.1074/jbc.M609534200
  • Primary Citation of Related Structures:
    2ISV, 2ISW

  • PubMed Abstract:

    Class I and class II fructose-1,6-bisphosphate aldolases (FBPA), glycolytic pathway enzymes, exhibit no amino acid sequence homology and utilize two different catalytic mechanisms. The mammalian class I FBPA employs a Schiff base mechanism, whereas the human parasitic protozoan Giardia lamblia class II FBPA is a zinc-dependent enzyme. In this study, we have explored the potential exploitation of the Giardia FBPA as a drug target. First, synthesis of FBPA was demonstrated in Giardia trophozoites by using an antibody-based fluorescence assay. Second, inhibition of FBPA gene transcription in Giardia trophozoites suggested that the enzyme is necessary for the survival of the organism under optimal laboratory growth conditions. Third, two crystal structures of FBPA in complex with the transition state analog phosphoglycolohydroxamate (PGH) show that the enzyme is homodimeric and that its active site contains a zinc ion. In one crystal form, each subunit contains PGH, which is coordinated to the zinc ion through the hydroxamic acid hydroxyl and carbonyl oxygen atoms. The second crystal form contains PGH only in one subunit and the active site of the second subunit is unoccupied. Inspection of the two states of the enzyme revealed that it undergoes a conformational transition upon ligand binding. The enzyme cleaves d-fructose-1,6-bisphosphate but not d-tagatose-1,6-bisphosphate, which is a tight binding competitive inhibitor. The essential role of the active site residue Asp-83 in catalysis was demonstrated by amino acid replacement. Determinants of catalysis and substrate recognition, derived from comparison of the G. lamblia FBPA structure with Escherichia coli FBPA and with a closely related enzyme, E. coli tagatose-1,6-bisphosphate aldolase (TBPA), are described.


  • Organizational Affiliation

    Center for Advanced Research in Biotechnology, University of Maryland Biotechnology Institute, Rockville, Maryland 20850.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Putative fructose-1,6-bisphosphate aldolase
A, B
323Giardia intestinalisMutation(s): 0
Gene Names: ald
EC: 4.1.2.13
UniProt
Find proteins for A8B2U2 (Giardia intestinalis (strain ATCC 50803 / WB clone C6))
Explore A8B2U2
Go to UniProtKB:  A8B2U2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA8B2U2
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.261
  • R-Value Work: 0.199
  • Space Group: P 61
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 62.36α = 90
b = 62.36β = 90
c = 319.86γ = 120
Software Package:
Software NamePurpose
ADSCdata collection
CNSrefinement
DENZOdata reduction
SCALEPACKdata scaling
CNSphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2006-12-12
    Type: Initial release
  • Version 1.1: 2008-05-01
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2023-08-30
    Changes: Data collection, Database references, Derived calculations, Refinement description
