4C6Y

Ancestral PNCA (last common ancestors of Gram-positive and Gram- negative bacteria) beta-lactamase class A


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free: 0.170
  • R-Value Work: 0.142
  • R-Value Observed: 0.143

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 2.0 of the entry. See complete history


Literature

Phenotypic Comparisons of Consensus Variants Versus Laboratory Resurrections of Precambrian Proteins.

Risso, V.A.Gavira, J.A.Gaucher, E.A.Sanchez-Ruiz, J.M.

(2014) Proteins 82: 887

  • DOI: https://doi.org/10.1002/prot.24575
  • Primary Citation of Related Structures:
    4C6Y, 4C75

  • PubMed Abstract:

    Consensus-sequence engineering has generated protein variants with enhanced stability, and sometimes, with modulated biological function. Consensus mutations are often interpreted as the introduction of ancestral amino acid residues. However, the precise relationship between consensus engineering and ancestral protein resurrection is not fully understood. Here, we report the properties of proteins encoded by consensus sequences derived from a multiple sequence alignment of extant, class A β-lactamases, as compared with the properties of ancient Precambrian β-lactamases resurrected in the laboratory. These comparisons considered primary sequence, secondary, and tertiary structure, as well as stability and catalysis against different antibiotics. Out of the three consensus variants generated, one could not be expressed and purified (likely due to misfolding and/or low stability) and only one displayed substantial stability having substrate promiscuity, although to a lower extent than ancient β-lactamases. These results: (i) highlight the phenotypic differences between consensus variants and laboratory resurrections of ancestral proteins; (ii) question interpretations of consensus proteins as phenotypic proxies of ancestral proteins; and (iii) support the notion that ancient proteins provide a robust approach toward the preparation of protein variants having large numbers of mutational changes while possessing unique biomolecular properties.


  • Organizational Affiliation

    Departamento de Quimica Fisica, Facultad de Ciencias, Universidad de Granada, 18071, Spain.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
BETA-LACTAMASE
A, B
262synthetic constructMutation(s): 0
EC: 3.5.2.6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 6 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
PG4
Query on PG4

Download Ideal Coordinates CCD File
C [auth A],
EA [auth B]
TETRAETHYLENE GLYCOL
C8 H18 O5
UWHCKJMYHZGTIT-UHFFFAOYSA-N
PEG
Query on PEG

Download Ideal Coordinates CCD File
AA [auth B]
BA [auth B]
CA [auth B]
D [auth A]
F [auth A]
AA [auth B],
BA [auth B],
CA [auth B],
D [auth A],
F [auth A],
G [auth A],
I [auth A],
J [auth A],
K [auth A],
L [auth A],
M [auth A],
N [auth A],
O [auth A],
P [auth A],
Q [auth A],
S [auth A],
U [auth B],
W [auth B],
X [auth B],
Y [auth B],
Z [auth B]
DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
GOL
Query on GOL

Download Ideal Coordinates CCD File
R [auth A]GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
ACT
Query on ACT

Download Ideal Coordinates CCD File
DA [auth B],
H [auth A]
ACETATE ION
C2 H3 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-M
CL
Query on CL

Download Ideal Coordinates CCD File
V [auth B]CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
NA
Query on NA

Download Ideal Coordinates CCD File
E [auth A],
T [auth A]
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free: 0.170
  • R-Value Work: 0.142
  • R-Value Observed: 0.143
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 39.581α = 90
b = 57.473β = 90
c = 240.401γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
SCALAdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2014-04-16
    Type: Initial release
  • Version 1.1: 2014-05-28
    Changes: Database references
  • Version 1.2: 2017-09-13
    Changes: Data collection
  • Version 2.0: 2023-12-20
    Changes: Atomic model, Data collection, Database references, Derived calculations, Other, Refinement description
