4WBS | pdb_00004wbs

Crystal structure of an ABC transporter related protein from Burkholderia phymatum

• PDB DOI: https://doi.org/10.2210/pdb4WBS/pdb

• Classification: TRANSPORT PROTEIN
• Organism(s): Paraburkholderia phymatum STM815
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2014-09-03 Released: 2014-09-24
• Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free:
  0.237 (Depositor), 0.240 (DCC)
• R-Value Work:
  0.183 (Depositor), 0.190 (DCC)
• R-Value Observed:
  0.186 (Depositor)

Starting Model: experimental

Literature

Crystal structure of an ABC transporter related protein from Burkholderia phymatum

Seattle Structural Genomics Center for Infectious Disease (SSGCID), Abendroth, J., Clifton, M.C., Sankaran, B., Lorimer, D., Edwards, T.E.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 61.2 kDa
• Atom Count: 4,017
• Modelled Residue Count: 503
• Deposited Residue Count: 564
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
ABC transporter related	A, B	282	Paraburkholderia phymatum STM815	Mutation(s): 0  Gene Names: Bphy_0327
UniProt
Find proteins for B2JCQ1 (Paraburkholderia phymatum (strain DSM 17167 / CIP 108236 / LMG 21445 / STM815)) Explore B2JCQ1  Go to UniProtKB:  B2JCQ1

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
CL	C [auth A], D [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free:  0.237 (Depositor), 0.240 (DCC)
• R-Value Work:  0.183 (Depositor), 0.190 (DCC)
• R-Value Observed: 0.186 (Depositor)

Diffraction Data: https://doi.org/10.18430/M34WBS

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 54.07	α = 90
b = 79.85	β = 90
c = 121.14	γ = 90

Software Package:

Software Name	Purpose
XDS	data reduction
BALBES	phasing
PHASER	phasing
PHENIX	refinement
PDB_EXTRACT	data extraction
XSCALE	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2014-09-24
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Revision History

• Version 1.0: 2014-09-24
  Type: Initial release

• Version 1.1: 2015-02-04
  Changes: Derived calculations
• Version 1.2: 2017-11-22
  Changes: Derived calculations, Other, Refinement description, Source and taxonomy, Structure summary
• Version 1.3: 2023-09-27
  Changes: Data collection, Database references, Refinement description
