4ZSW

Pig Brain GABA-AT inactivated by (E)-(1S,3S)-3-Amino-4-fluoromethylenyl-1-cyclopentanoic acid


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free: 0.195
  • R-Value Work: 0.158
  • R-Value Observed: 0.159

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 2.1 of the entry. See complete history


Literature

Mechanism of Inactivation of GABA Aminotransferase by (E)- and (Z)-(1S,3S)-3-Amino-4-fluoromethylenyl-1-cyclopentanoic Acid.

Lee, H.Le, H.V.Wu, R.Doud, E.Sanishvili, R.Kellie, J.F.Compton, P.D.Pachaiyappan, B.Liu, D.Kelleher, N.L.Silverman, R.B.

(2015) ACS Chem Biol 10: 2087-2098

  • DOI: https://doi.org/10.1021/acschembio.5b00212
  • Primary Citation of Related Structures:
    4ZSW, 4ZSY

  • PubMed Abstract:

    When γ-aminobutyric acid (GABA), the major inhibitory neurotransmitter in the mammalian central nervous system, falls below a threshold level, seizures occur. One approach to raise GABA concentrations is to inhibit GABA aminotransferase (GABA-AT), a pyridoxal 5'-phosphate-dependent enzyme that degrades GABA. We have previously developed (1S,3S)-3-amino-4-difluoromethylene-1-cyclopentanoic acid (CPP-115), which is 186 times more efficient in inactivating GABA-AT than vigabatrin, the only FDA-approved inactivator of GABA-AT. We also developed (E)- and (Z)-(1S,3S)-3-amino-4-fluoromethylenyl-1-cyclopentanoic acid (1 and 2, respectively), monofluorinated analogs of CPP-115, which are comparable to vigabatrin in inactivating GABA-AT. Here, we report the mechanism of inactivation of GABA-AT by 1 and 2. Both produce a metabolite that induces disruption of the Glu270-Arg445 salt bridge to accommodate interaction between the metabolite formyl group and Arg445. This is the second time that Arg445 has interacted with a ligand and is involved in GABA-AT inactivation, thereby confirming the importance of Arg445 in future inactivator design.


  • Organizational Affiliation

    Departments of Chemistry and Molecular Biosciences, Chemistry of Life Processes Institute, and the Center for Molecular Innovation and Drug Discovery, Northwestern University , Evanston, Illinois 60208, United States.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
4-aminobutyrate aminotransferase, mitochondrial
A, B, C, D
461Sus scrofaMutation(s): 0
Gene Names: ABATGABAT
EC: 2.6.1.19 (PDB Primary Data), 2.6.1.22 (PDB Primary Data)
UniProt
Find proteins for P80147 (Sus scrofa)
Explore P80147
Go to UniProtKB:  P80147
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP80147
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
RW2
Query on RW2

Download Ideal Coordinates CCD File
F [auth A],
H [auth B],
L [auth C],
M [auth D]
(1S)-4-[({3-hydroxy-2-methyl-5-[(phosphonooxy)methyl]pyridin-4-yl}methyl)amino]cyclopent-3-ene-1,3-dicarboxylic acid
C15 H19 N2 O9 P
VNQKGJPXVHNUEY-QMMMGPOBSA-N
FES
Query on FES

Download Ideal Coordinates CCD File
E [auth A],
I [auth C]
FE2/S2 (INORGANIC) CLUSTER
Fe2 S2
NIXDOXVAJZFRNF-UHFFFAOYSA-N
GOL
Query on GOL

Download Ideal Coordinates CCD File
G [auth B],
J [auth C]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
ACT
Query on ACT

Download Ideal Coordinates CCD File
K [auth C]ACETATE ION
C2 H3 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-M
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free: 0.195
  • R-Value Work: 0.158
  • R-Value Observed: 0.159
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 69.601α = 90
b = 227.614β = 108.97
c = 71.343γ = 90
Software Package:
Software NamePurpose
SCALEPACKdata scaling
PHENIXrefinement
PDB_EXTRACTdata extraction
HKL-2000data reduction
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM066132
National Institutes of Health/National Institute on Drug Abuse (NIH/NIDA)United StatesDA030604
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM067725
National Institutes of Health/National Cancer Institute (NIH/NCI)United StatesACB-12002
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesAGM-12006
Department of Energy (DOE, United States)United StatesDE-AC02-06CH11357

Revision History  (Full details and data files)

  • Version 1.0: 2015-07-08
    Type: Initial release
  • Version 1.1: 2015-09-30
    Changes: Database references
  • Version 1.2: 2017-09-20
    Changes: Advisory, Author supporting evidence, Derived calculations
  • Version 1.3: 2019-12-04
    Changes: Advisory, Author supporting evidence
  • Version 1.4: 2019-12-11
    Changes: Author supporting evidence
  • Version 2.0: 2021-01-13
    Changes: Advisory, Atomic model, Data collection, Derived calculations, Non-polymer description, Structure summary
  • Version 2.1: 2024-03-06
    Changes: Advisory, Data collection, Database references
