6BAL | pdb_00006bal

2.1 Angstrom Resolution Crystal Structure of Malate Dehydrogenase from Haemophilus influenzae in Complex with L-Malate

PDB DOI: https://doi.org/10.2210/pdb6BAL/pdb

Classification: OXIDOREDUCTASE
Organism(s): Haemophilus influenzae Rd KW20
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2017-10-13 Released: 2017-10-25
Deposition Author(s): Minasov, G., Wawrzak, Z., Skarina, T., Grimshaw, S., Satchell, K.J.F., Savchenko, A., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free:
0.219 (Depositor), 0.220 (DCC)
R-Value Work:
0.170 (Depositor), 0.180 (DCC)
R-Value Observed:
0.172 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.1 of the entry. See complete history.

Literature

2.1 Angstrom Resolution Crystal Structure of Malate Dehydrogenase from Haemophilus influenzae in Complex with L-Malate

Minasov, G., Wawrzak, Z., Skarina, T., Grimshaw, S., Satchell, K.J.F., Savchenko, A., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

To be published.

Macromolecule Content

Total Structure Weight: 283.28 kDa
Atom Count: 19,775
Modelled Residue Count: 2,491
Deposited Residue Count: 2,680
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Malate dehydrogenase	A, B, C, D, E A, B, C, D, E, F, G, H	335	Haemophilus influenzae Rd KW20	Mutation(s): 0 Gene Names: mdh, HI_1210 EC: 1.1.1.37
UniProt
Find proteins for P44427 (Haemophilus influenzae (strain ATCC 51907 / DSM 11121 / KW20 / Rd)) Explore P44427 Go to UniProtKB: P44427
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P44427
Sequence Annotations Expand
Reference Sequence LOADING

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
LMR Query on LMR Download Ideal Coordinates CCD File SDF format, chain I [auth A] MOL2 format, chain I [auth A] mmCIF format, chain I [auth A]	I [auth A]	(2S)-2-hydroxybutanedioic acid C₄ H₆ O₅ BJEPYKJPYRNKOW-REOHCLBHSA-N		Interactions Focus chain I [auth A] Interactions & Density Focus chain I [auth A]
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain L [auth B] SDF format, chain M [auth B] SDF format, chain N [auth C] SDF format, chain O [auth C] SDF format, chain P [auth C] SDF format, chain Q [auth D] SDF format, chain S [auth E] SDF format, chain T [auth E] SDF format, chain U [auth E] SDF format, chain V [auth F] SDF format, chain W [auth F] SDF format, chain X [auth G] SDF format, chain Y [auth G] SDF format, chain Z [auth H] SDF format, chain R [auth D] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain L [auth B] MOL2 format, chain M [auth B] MOL2 format, chain N [auth C] MOL2 format, chain O [auth C] MOL2 format, chain P [auth C] MOL2 format, chain Q [auth D] MOL2 format, chain S [auth E] MOL2 format, chain T [auth E] MOL2 format, chain U [auth E] MOL2 format, chain V [auth F] MOL2 format, chain W [auth F] MOL2 format, chain X [auth G] MOL2 format, chain Y [auth G] MOL2 format, chain Z [auth H] MOL2 format, chain R [auth D] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A] mmCIF format, chain L [auth B] mmCIF format, chain M [auth B] mmCIF format, chain N [auth C] mmCIF format, chain O [auth C] mmCIF format, chain P [auth C] mmCIF format, chain Q [auth D] mmCIF format, chain S [auth E] mmCIF format, chain T [auth E] mmCIF format, chain U [auth E] mmCIF format, chain V [auth F] mmCIF format, chain W [auth F] mmCIF format, chain X [auth G] mmCIF format, chain Y [auth G] mmCIF format, chain Z [auth H] mmCIF format, chain R [auth D]	J [auth A] K [auth A] L [auth B] M [auth B] N [auth C] J [auth A], K [auth A], L [auth B], M [auth B], N [auth C], O [auth C], P [auth C], Q [auth D], R [auth D], S [auth E], T [auth E], U [auth E], V [auth F], W [auth F], X [auth G], Y [auth G], Z [auth H]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth B] Focus chain M [auth B] Focus chain N [auth C] Focus chain O [auth C] Focus chain P [auth C] Focus chain Q [auth D] Focus chain R [auth D] Focus chain S [auth E] Focus chain T [auth E] Focus chain U [auth E] Focus chain V [auth F] Focus chain W [auth F] Focus chain X [auth G] Focus chain Y [auth G] Focus chain Z [auth H] Interactions & Density Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth B] Focus chain M [auth B] Focus chain N [auth C] Focus chain O [auth C] Focus chain P [auth C] Focus chain Q [auth D] Focus chain R [auth D] Focus chain S [auth E] Focus chain T [auth E] Focus chain U [auth E] Focus chain V [auth F] Focus chain W [auth F] Focus chain X [auth G] Focus chain Y [auth G] Focus chain Z [auth H]
