7F1H

Designed enzyme RA61 M48K/I72D mutant: form I


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.14 Å
  • R-Value Free: 0.147
  • R-Value Work: 0.124
  • R-Value Observed: 0.126

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history


Literature

Varying the Directionality of Protein Catalysts for Aldol and Retro-Aldol Reactions.

Fujioka, T.Numoto, N.Akama, H.Shilpa, K.Oka, M.Roy, P.K.Krishna, Y.Ito, N.Baker, D.Oda, M.Tanaka, F.

(2022) Chembiochem 23: e202100435-e202100435

  • DOI: https://doi.org/10.1002/cbic.202100435
  • Primary Citation of Related Structures:
    7F1H, 7F1I, 7F1J, 7F1K, 7F1L

  • PubMed Abstract:

    Natural aldolase enzymes and created retro-aldolase protein catalysts often catalyze both aldol and retro-aldol reactions depending on the concentrations of the reactants and the products. Here, we report that the directionality of protein catalysts can be altered by replacing one amino acid. The protein catalyst derived from a scaffold of a previously reported retro-aldolase catalyst, catalyzed aldol reactions more efficiently than the previously reported retro-aldolase catalyst. The retro-aldolase catalyst efficiently catalyzed the retro-aldol reaction but was less efficient in catalyzing the aldol reaction. The results indicate that protein catalysts with varying levels of directionality in usually reversibly catalyzed aldol and retro-aldol reactions can be generated from the same protein scaffold.


  • Organizational Affiliation

    Graduate School of Life and Environmental Sciences, Kyoto Prefectural University, 1-5 Hangi-cho, Shimogamo, Sakyo-ku, Kyoto, Kyoto, 606-8522, Japan.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Engineered Retroaldolase201synthetic constructMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.14 Å
  • R-Value Free: 0.147
  • R-Value Work: 0.124
  • R-Value Observed: 0.126
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 35.644α = 90
b = 64.236β = 111.074
c = 42.682γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XDSdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2021-11-24
    Type: Initial release
  • Version 1.1: 2022-02-16
    Changes: Database references
  • Version 1.2: 2022-03-16
    Changes: Database references
  • Version 1.3: 2023-11-29
    Changes: Data collection, Refinement description
