7SKY

Pertussis toxin S1 bound to NAD+


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.37 Å
  • R-Value Free: 0.224
  • R-Value Work: 0.202
  • R-Value Observed: 0.203

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history


Literature

Crystal structures of pertussis toxin with NAD + and analogs provide structural insights into the mechanism of its cytosolic ADP-ribosylation activity.

Sakari, M.Tran, M.T.Rossjohn, J.Pulliainen, A.T.Beddoe, T.Littler, D.R.

(2022) J Biol Chem 298: 101892-101892

  • DOI: https://doi.org/10.1016/j.jbc.2022.101892
  • Primary Citation of Related Structures:
    7SKI, 7SKK, 7SKY, 7SNE, 7U6Z

  • PubMed Abstract:

    Bordetella pertussis is the causative agent of whooping cough, a highly contagious respiratory disease. Pertussis toxin (PT), a major virulence factor secreted by B. pertussis, is an AB5-type protein complex topologically related to cholera toxin. The PT protein complex is internalized by host cells and follows a retrograde trafficking route to the endoplasmic reticulum, where it subsequently dissociates. The released enzymatic S1 subunit is then translocated from the endoplasmic reticulum into the cytosol and subsequently ADP-ribosylates the inhibitory alpha-subunits (Gαi) of heterotrimeric G proteins, thus promoting dysregulation of G protein-coupled receptor signaling. However, the mechanistic details of the ADP-ribosylation activity of PT are not well understood. Here, we describe crystal structures of the S1 subunit in complex with nicotinamide adenine dinucleotide (NAD+), with NAD+ hydrolysis products ADP-ribose and nicotinamide, with NAD+ analog PJ34, and with a novel NAD+ analog formed upon S1 subunit crystallization with 3-amino benzamide and NAD+, which we name benzamide amino adenine dinucleotide. These crystal structures provide unprecedented insights into pre- and post-NAD+ hydrolysis steps of the ADP-ribosyltransferase activity of PT. We propose that these data may aid in rational drug design approaches and further development of PT-specific small-molecule inhibitors.


  • Organizational Affiliation

    Institute of Biomedicine, Research Unit for Infection and Immunity, University of Turku, Turku, Finland.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Pertussis toxin subunit 1A [auth B],
B [auth A],
C,
D
184Bordetella pertussisMutation(s): 1
Gene Names: ptxABP3783
EC: 2.4.2 (PDB Primary Data), 2.4.2.30 (PDB Primary Data)
UniProt
Find proteins for P04977 (Bordetella pertussis (strain Tohama I / ATCC BAA-589 / NCTC 13251))
Explore P04977
Go to UniProtKB:  P04977
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP04977
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.37 Å
  • R-Value Free: 0.224
  • R-Value Work: 0.202
  • R-Value Observed: 0.203
  • Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 34.6α = 90.73
b = 68.25β = 90.27
c = 71.67γ = 91.45
Software Package:
Software NamePurpose
PHENIXrefinement
PHENIXrefinement
MOSFLMdata reduction
SCALAdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Australian Research Council (ARC)Australia--

Revision History  (Full details and data files)

  • Version 1.0: 2022-04-13
    Type: Initial release
  • Version 1.1: 2022-04-20
    Changes: Database references
  • Version 1.2: 2022-05-18
    Changes: Database references
  • Version 1.3: 2023-10-18
    Changes: Data collection, Refinement description
