7OGZ

Plant peptide hormone receptor complex H1L3S1


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free: 0.371
  • R-Value Work: 0.353

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

HSL1 and BAM1/2 impact epidermal cell development by sensing distinct signaling peptides.

Roman, A.O.Jimenez-Sandoval, P.Augustin, S.Broyart, C.Hothorn, L.A.Santiago, J.

(2022) Nat Commun 13: 876-876

  • DOI: https://doi.org/10.1038/s41467-022-28558-4
  • Primary Citation of Related Structures:
    7ODK, 7ODV, 7OGO, 7OGQ, 7OGU, 7OGZ

  • PubMed Abstract:

    The membrane receptor kinases HAESA and HSL2 recognize a family of IDA/IDL signaling peptides to control cell separation processes in different plant organs. The homologous HSL1 has been reported to regulate epidermal cell patterning by interacting with a different class of signaling peptides from the CLE family. Here we demonstrate that HSL1 binds IDA/IDL peptides with high, and CLE peptides with lower affinity, respectively. Ligand sensing capability and receptor activation of HSL1 require a SERK co-receptor kinase. Crystal structures with IDA/IDLs or with CLE9 reveal that HSL1-SERK1 complex recognizes the entire IDA/IDL signaling peptide, while only parts of CLE9 are bound to the receptor. In contrast, the receptor kinase BAM1 interacts with the entire CLE9 peptide with high affinity and specificity. Furthermore, the receptor tandem BAM1/BAM2 regulates epidermal cell division homeostasis. Consequently, HSL1-IDLs and BAM1/BAM2-CLEs independently regulate cell patterning in the leaf epidermal tissue.


  • Organizational Affiliation

    The Plant Signaling Mechanisms Laboratory, Department of Plant Molecular Biology, University of Lausanne, 1015, Lausanne, Switzerland.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Receptor-like protein kinase HSL1A [auth AAA],
D [auth DDD]
617Arabidopsis thalianaMutation(s): 0
Gene Names: HSL1At1g28440F3M18.12
EC: 2.7.11.1
UniProt
Find proteins for Q9SGP2 (Arabidopsis thaliana)
Explore Q9SGP2
Go to UniProtKB:  Q9SGP2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9SGP2
Glycosylation
Glycosylation Sites: 7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Somatic embryogenesis receptor kinase 1B [auth BBB],
E [auth EEE]
201Arabidopsis thalianaMutation(s): 0
Gene Names: SERK1At1g71830F14O23.21F14O23_24
EC: 2.7.10.1 (PDB Primary Data), 2.7.11.1 (PDB Primary Data)
UniProt
Find proteins for Q94AG2 (Arabidopsis thaliana)
Explore Q94AG2
Go to UniProtKB:  Q94AG2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ94AG2
Glycosylation
Glycosylation Sites: 1
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Peptide hormone IDL3C [auth CCC],
F [auth FFF]
12Arabidopsis thalianaMutation(s): 0
Gene Names: IDL3At5g09805F17I14MYH9
UniProt
Find proteins for Q6DUW7 (Arabidopsis thaliana)
Explore Q6DUW7
Go to UniProtKB:  Q6DUW7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6DUW7
Sequence Annotations
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 4
MoleculeChains Length2D Diagram Glycosylation3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
G [auth AaA],
I [auth AgA],
J [auth AiA],
K [auth BaB],
M [auth DbD],
G [auth AaA],
I [auth AgA],
J [auth AiA],
K [auth BaB],
M [auth DbD],
N [auth DcD],
O [auth DeD],
P [auth DhD],
Q [auth DkD],
R [auth EaE]
2N-Glycosylation
Glycosylation Resources
GlyTouCan:  G42666HT
GlyCosmos:  G42666HT
GlyGen:  G42666HT
Entity ID: 5
MoleculeChains Length2D Diagram Glycosylation3D Interactions
beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranoseH [auth AeA],
L [auth DaD]
3N-Glycosylation
Glycosylation Resources
GlyTouCan:  G15407YE
GlyCosmos:  G15407YE
GlyGen:  G15407YE
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free: 0.371
  • R-Value Work: 0.353
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 89.838α = 90
b = 144.501β = 90
c = 168.432γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
Aimlessdata scaling
xia2data reduction
Cootmodel building
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Swiss National Science FoundationSwitzerland31003A_173101

Revision History  (Full details and data files)

  • Version 1.0: 2022-02-16
    Type: Initial release
  • Version 1.1: 2022-03-02
    Changes: Database references
  • Version 1.2: 2024-01-31
    Changes: Data collection, Derived calculations, Refinement description
