2FB4

DIR PRIMAERSTRUKTUR DES KRISTALLISIERBAREN MONOKLONALEN IMMUNOGLOBULINS IGG1 KOL. II. AMINOSAEURESEQUENZ DER L-KETTE, LAMBDA-TYP, SUBGRUPPE I (GERMAN)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Work: 0.189

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history


Literature

The primary structure of crystallizable monoclonal immunoglobulin IgG1 Kol. II. Amino acid sequence of the L-chain, gamma-type, subgroup I

Kratzin, H.D.Palm, W.Stangel, M.Schmidt, W.E.Friedrich, J.Hilschmann, N.

(1989) Biol Chem Hoppe Seyler 370: 263-272

  • Primary Citation of Related Structures:
    2FB4, 2IG2

  • PubMed Abstract:

    The immunoglobulin Kol was the first intact antibody molecule which was characterized by high-resolution X-ray crystallography. Furthermore the complete amino-acid sequence of the heavy (H)-chain is known. Here we report the complete amino-acid sequence of the light (L)-chain of the monoclonal immunoglobulin Kol (IgG1). The polypeptide has an Mr of 22,781, consists of 216 amino acids and due to its structure is of the lambda-type. With the characteristic amino acids threonine, asparagine, threonine, glycine and lysine in positions 101, 114, 116, 154, and 165, respectively the Kol L-chain is of the Mcg isotype. With the proteins Mcg, Mot, Bur, Loc and Mem six myeloma-derived amino-acid sequences of the same isotype are known. The amino-acid sequence of the N-terminal variable part is characteristic of subgroup 1. This contribution completes the primary structure of IgG1 Kol.


  • Organizational Affiliation

    max-Planck-Institut für experimentelle Medizin, Abteilung Immunchemie, Göttingen.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
IGG1-LAMBDA KOL FAB (LIGHT CHAIN)A [auth L]216Homo sapiensMutation(s): 0
UniProt
Find proteins for P0CG04 (Homo sapiens)
Explore P0CG04
Go to UniProtKB:  P0CG04
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0CG04
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
IGG1-LAMBDA KOL FAB (HEAVY CHAIN)B [auth H]229Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P01772 (Homo sapiens)
Explore P01772
Go to UniProtKB:  P01772
GTEx:  ENSG00000211955
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP01772
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Work: 0.189
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 78.3α = 90
b = 138.9β = 90
c = 40γ = 90
Software Package:
Software NamePurpose
EREFrefinement

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 1989-07-12
    Type: Initial release
  • Version 1.1: 2008-03-24
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2024-06-05
    Changes: Data collection, Database references, Derived calculations, Other
  • Version 1.4: 2024-11-20
    Changes: Structure summary
