3GG9 | pdb_00003gg9

CRYSTAL STRUCTURE OF putative D-3-phosphoglycerate dehydrogenase oxidoreductase from Ralstonia solanacearum

PDB DOI: https://doi.org/10.2210/pdb3GG9/pdb

Classification: OXIDOREDUCTASE
Organism(s): Ralstonia solanacearum
Mutation(s): No

Deposited: 2009-02-27 Released: 2009-03-24
Deposition Author(s): Patskovsky, Y., Ramagopal, U., Toro, R., Morano, C., Freeman, J., Chang, S., Sauder, J.M., Burley, S.K., Almo, S.C., New York SGX Research Center for Structural Genomics (NYSGXRC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free:
0.261 (Depositor), 0.260 (DCC)
R-Value Work:
0.199 (Depositor), 0.200 (DCC)
R-Value Observed:
0.201 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 1.4 of the entry. See complete history.

Literature

Crystal Structure of Putative D-3-Phosphoglycerate Dehydrogenase from Ralstonia Solanacearum

Patskovsky, Y., Ramagopal, U., Toro, R., Morano, C., Freeman, J., Chang, S., Sauder, J.M., Burley, S.K., Almo, S.C.

To be published.

Macromolecule Content

Total Structure Weight: 156.73 kDa
Atom Count: 11,868
Modelled Residue Count: 1,366
Deposited Residue Count: 1,408
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
d-3-phosphoglycerate dehydrogenase oxidoreductase protein	A, B, C, D	352	Ralstonia solanacearum	Mutation(s): 0 Gene Names: serA, RSc0016 EC: 1.1.1.95
UniProt
Find proteins for Q8Y3G4 (Ralstonia nicotianae (strain ATCC BAA-1114 / GMI1000)) Explore Q8Y3G4 Go to UniProtKB: Q8Y3G4
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q8Y3G4
Sequence Annotations Expand
Reference Sequence LOADING

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
SO4 Query on SO4 Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain K [auth B] SDF format, chain L [auth B] SDF format, chain N [auth C] SDF format, chain O [auth C] SDF format, chain Q [auth D] SDF format, chain R [auth D] SDF format, chain S [auth D] SDF format, chain T [auth D] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain K [auth B] MOL2 format, chain L [auth B] MOL2 format, chain N [auth C] MOL2 format, chain O [auth C] MOL2 format, chain Q [auth D] MOL2 format, chain R [auth D] MOL2 format, chain S [auth D] MOL2 format, chain T [auth D] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain K [auth B] mmCIF format, chain L [auth B] mmCIF format, chain N [auth C] mmCIF format, chain O [auth C] mmCIF format, chain Q [auth D] mmCIF format, chain R [auth D] mmCIF format, chain S [auth D] mmCIF format, chain T [auth D]	E [auth A] F [auth A] G [auth A] K [auth B] L [auth B] E [auth A], F [auth A], G [auth A], K [auth B], L [auth B], N [auth C], O [auth C], Q [auth D], R [auth D], S [auth D], T [auth D]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain K [auth B] Focus chain L [auth B] Focus chain N [auth C] Focus chain O [auth C] Focus chain Q [auth D] Focus chain R [auth D] Focus chain S [auth D] Focus chain T [auth D] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain K [auth B] Focus chain L [auth B] Focus chain N [auth C] Focus chain O [auth C] Focus chain Q [auth D] Focus chain R [auth D] Focus chain S [auth D] Focus chain T [auth D]
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain M [auth B] SDF format, chain V [auth D] SDF format, chain W [auth D] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain M [auth B] MOL2 format, chain V [auth D] MOL2 format, chain W [auth D] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain M [auth B] mmCIF format, chain V [auth D] mmCIF format, chain W [auth D]	H [auth A] I [auth A] J [auth A] M [auth B] V [auth D] H [auth A], I [auth A], J [auth A], M [auth B], V [auth D], W [auth D]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain M [auth B] Focus chain V [auth D] Focus chain W [auth D] Interactions & Density Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain M [auth B] Focus chain V [auth D] Focus chain W [auth D]
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain P [auth C] SDF format, chain U [auth D] MOL2 format, chain P [auth C] MOL2 format, chain U [auth D] mmCIF format, chain P [auth C] mmCIF format, chain U [auth D]	P [auth C], U [auth D]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain P [auth C] Focus chain U [auth D] Interactions & Density Focus chain P [auth C] Focus chain U [auth D]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free: 0.261 (Depositor), 0.260 (DCC)
R-Value Work: 0.199 (Depositor), 0.200 (DCC)
R-Value Observed: 0.201 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 92.034	α = 90
b = 97.625	β = 114.96
c = 97.808	γ = 90

Software Package:

Software Name	Purpose
SHELX	model building
REFMAC	refinement
HKL-2000	data reduction
HKL-2000	data scaling
SHELX	phasing

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2009-03-24

Deposition Author(s):

New York SGX Research Center for Structural Genomics (NYSGXRC)

Revision History (Full details and data files)

Version 1.0: 2009-03-24
Type: Initial release
Version 1.1: 2011-07-13
Changes: Non-polymer description, Version format compliance
Version 1.2: 2018-11-21
Changes: Data collection, Structure summary
Version 1.3: 2021-02-10
Changes: Database references, Derived calculations, Structure summary
Version 1.4: 2024-02-21
Changes: Data collection, Database references
