3TUG | pdb_00003tug

Crystal structure of the HECT domain of ITCH E3 ubiquitin ligase

PDB DOI: https://doi.org/10.2210/pdb3TUG/pdb

Classification: LIGASE
Organism(s): Homo sapiens
Expression System: Escherichia coli BL21
Mutation(s): Yes

Deposited: 2011-09-16 Released: 2011-10-12
Deposition Author(s): Dong, A., Dobrovetsky, E., Xue, S., Butler, C., Wernimont, A., Walker, J.R., Tempel, W., Dhe-Paganon, S., Arrowsmith, C.H., Edwards, A.M., Bountra, C., Tong, Y., Structural Genomics Consortium (SGC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.27 Å
R-Value Free:
0.256 (Depositor), 0.260 (DCC)
R-Value Work:
0.196 (Depositor), 0.210 (DCC)
R-Value Observed:
0.198 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of the HECT domain of ITCH E3 ubiquitin ligase

Dobrovetsky, E., Dong, A., Xue, S., Butler, C., Wernimont, A., Walker, J.R., Tempel, W., Dhe-Paganon, S., Arrowsmith, C.H., Edwards, A.M., Bountra, C., Tong, Y.

To be published.

Macromolecule Content

Total Structure Weight: 47.53 kDa
Atom Count: 2,771
Modelled Residue Count: 334
Deposited Residue Count: 398
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
E3 ubiquitin-protein ligase Itchy homolog	A	398	Homo sapiens	Mutation(s): 2 Gene Names: ITCH EC: 6.3.2 (PDB Primary Data), 2.3.2.26 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for Q96J02 (Homo sapiens) Explore Q96J02 Go to UniProtKB: Q96J02
PHAROS: Q96J02 GTEx: ENSG00000078747
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q96J02
Sequence Annotations Expand
Reference Sequence LOADING

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
UNX Query on UNX Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A]	C [auth A] D [auth A] E [auth A] F [auth A] G [auth A] C [auth A], D [auth A], E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], J [auth A], K [auth A]	UNKNOWN ATOM OR ION X		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.27 Å
R-Value Free: 0.256 (Depositor), 0.260 (DCC)
R-Value Work: 0.196 (Depositor), 0.210 (DCC)
R-Value Observed: 0.198 (Depositor)

Space Group: P 3₁ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 82.779	α = 90
b = 82.779	β = 90
c = 109.943	γ = 120

Software Package:

Software Name	Purpose
SBC-Collect	data collection
PHASER	phasing
BUSTER	refinement
Coot	model building
HKL-3000	data reduction
HKL-3000	data scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2011-10-12

Deposition Author(s):

Structural Genomics Consortium (SGC)

Revision History (Full details and data files)

Version 1.0: 2011-10-12
Type: Initial release
Version 1.1: 2023-09-13
Changes: Data collection, Database references, Derived calculations, Refinement description
