6RCQ

PfRH5-binding monoclonal antibody R5.011


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.28 Å
  • R-Value Free: 0.227
  • R-Value Work: 0.185
  • R-Value Observed: 0.188

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Human Antibodies that Slow Erythrocyte Invasion Potentiate Malaria-Neutralizing Antibodies.

Alanine, D.G.W.Quinkert, D.Kumarasingha, R.Mehmood, S.Donnellan, F.R.Minkah, N.K.Dadonaite, B.Diouf, A.Galaway, F.Silk, S.E.Jamwal, A.Marshall, J.M.Miura, K.Foquet, L.Elias, S.C.Labbe, G.M.Douglas, A.D.Jin, J.Payne, R.O.Illingworth, J.J.Pattinson, D.J.Pulido, D.Williams, B.G.de Jongh, W.A.Wright, G.J.Kappe, S.H.I.Robinson, C.V.Long, C.A.Crabb, B.S.Gilson, P.R.Higgins, M.K.Draper, S.J.

(2019) Cell 178: 216-228.e21

  • DOI: https://doi.org/10.1016/j.cell.2019.05.025
  • Primary Citation of Related Structures:
    6RCO, 6RCQ, 6RCS, 6RCU, 6RCV

  • PubMed Abstract:

    The Plasmodium falciparum reticulocyte-binding protein homolog 5 (PfRH5) is the leading target for next-generation vaccines against the disease-causing blood-stage of malaria. However, little is known about how human antibodies confer functional immunity against this antigen. We isolated a panel of human monoclonal antibodies (mAbs) against PfRH5 from peripheral blood B cells from vaccinees in the first clinical trial of a PfRH5-based vaccine. We identified a subset of mAbs with neutralizing activity that bind to three distinct sites and another subset of mAbs that are non-functional, or even antagonistic to neutralizing antibodies. We also identify the epitope of a novel group of non-neutralizing antibodies that significantly reduce the speed of red blood cell invasion by the merozoite, thereby potentiating the effect of all neutralizing PfRH5 antibodies as well as synergizing with antibodies targeting other malaria invasion proteins. Our results provide a roadmap for structure-guided vaccine development to maximize antibody efficacy against blood-stage malaria.


  • Organizational Affiliation

    The Jenner Institute, University of Oxford, Old Road Campus Research Building, Oxford OX3 7DQ, UK; Department of Biochemistry, University of Oxford, South Parks Road, Oxford OX1 3QU, UK.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
R5.011 heavy chain240Homo sapiensMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
R5.011 light chain217Homo sapiensMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.28 Å
  • R-Value Free: 0.227
  • R-Value Work: 0.185
  • R-Value Observed: 0.188
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 47.858α = 90
b = 86.375β = 90
c = 127.409γ = 90
Software Package:
Software NamePurpose
BUSTERrefinement
XDSdata reduction
XDSdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Wellcome TrustUnited Kingdom--

Revision History  (Full details and data files)

  • Version 1.0: 2019-06-26
    Type: Initial release
  • Version 1.1: 2019-07-10
    Changes: Data collection, Database references
  • Version 1.2: 2024-11-13
    Changes: Data collection, Database references, Structure summary
